Product Overview

1.2083 Plastic mould steel​​​​​​​ is a high-chromium martensitic stainless steel specifically designed for plastic injection moulds. Characterized by its high chrome content (13%), it offers exceptional resistance to corrosive plastic aggregates and humid storage environments. Delivered in either the annealed or pre-hardened condition, 1.2083 provides the perfect combination of mirror-grade polishability and high wear resistance after hardening, ensuring long-term production stability for high-precision components.

1.1.2083 Plastic mould steel Typical Chemical Composition:
C=0.36-0.45,Si≤0.6,Mn≤0.8,Cr=12.0-14.0,P≤0.035,S≤0.030

2.1.2083 Plastic mould steel Delivery Condition
Hot rolled/Forged,Black or Milled surface
QT(30-36HRC)
Annealed with hardness max 230HB

3.Size Specification:

Steel plate:20-120X1500-2500X3000-580mm

Steel Flat bar:10-120X310-810X2500-5800mm

Forged Block:125-500X610-1200X2000-5800mm

Round bar:Diameter 10-500X3000-5800mm

Mill origin:changcheng special steel,Tiangong mill,Dongbei special steel,Forged mill etc

4.1.2083 Plastic mould steel Key Features:

• Excellent Corrosion Resistance: Protects cooling channels and mould cavities from rust caused by corrosive plastics (PVC/Acetates) or humid climates.

• Superior Mirror Polishability: High cleanliness and fine microstructure allow for optical-grade surface finishes (#5000+ grit).

• High Wear Resistance: Achieves 50-54 HRC after heat treatment, providing outstanding durability for high-volume production.

• Good Machinability: Despite its high chromium content, it offers stable cutting performance in the annealed state.

• Low Maintenance Costs: Reduces the need for specialized anti-rust storage and frequent cavity cleaning.

5.1.2083 Plastic mould steel Typical Application:

• Corrosive Plastic Moulding: Processing PVC, amino plastics, and materials with flame retardants.

• Optical & Medical: Lenses, camera parts, surgical instruments, and clean-room syringes.

• High-Gloss Packaging: Cosmetic containers, perfume bottle caps, and luxury goods.

• Food Industry: Moulds for food packaging and cutlery requiring high hygiene standards.

6.Delivery time:
 --- 3-10days for ready stock
 ---15-60days for new production products

------------------------------------------------------------------------------------------------------------------------
