1.2312 Plastic Mould Steel

1.2312 Plastic Mould Steel

1.1.2312 Plastic Mould Steel Chemical composition:
C=0.35-0.45 Si=0.30-0.50 Mn=1.40-1.60 P≤0.030  S=0.05-0.10  Cr=1.8-2.0  Mo=0.15-0.25

2.1.2312 Plastic Mould Steel Delivery condition:
   Hot rolled, Black /Milled surface
   Q+T,hardness 28~34HRC
   As original edge/2 sides bandsaw cutting/4 sides bandsaw cutting
   Ultrasonic test according to SEP 1921-84 Gr3, Class C/c or D/d

   Hot Forged,Black/Milled surface.
   Q+T,hardness 28~36HRC
   2 ends bandsaw cutting/4 sides bandsaw cutting
   Ultrasonic test according to SEP 1921-84 Gr3, Class D/d

3.1.2312 Plastic Mould Steel Size specification:

We also can cut per your size requirements

4. Technical Data: According to the customer's requirement of Chemical Composition, Physical Properties and Mechanical Testing


5. Payment terms:TT or LC at sight or UPAS LC


6. Delivery time:
  ---For ready Stock Material:3-15 days after advanced payment or confirm the original L/C.
  ---For Future Material:25-60days after advanced payment or confirm the original L/C.

7.1.2312 Plastic Mould Steel Material character:
---Small quenching distortion.
---High strength, abrasive resistance and hardenability.

8.1.2312 Plastic Mould Steel Application:Die holders, zinc die casting dies, backers, bolsters and injection moulds

-------------------------------------------------------------------------------------------------------------

​​
