D2 Tool Steel Bar
Product Overview
D2 Tool Steel is a high-carbon, high-chromium air-hardening tool steel, characterized by its high surface hardness and exceptional wear resistance. Due to its high chromium content (12%), D2 Tool Steel offers slight corrosion resistance in the hardened condition. It is the industry's go-to material for long-run cold work applications that require a combination of high compressive strength and maximum resistance to abrasive wear. Its superior dimensional stability during heat treatment makes it ideal for complex, high-precision tools.
1.D2 Tool Steel Bar Steel Grade & Chemical Composition:
| Grade | Standard | C | Si | Mn | Cr | V | Mo | P | S |
| D2 | ASTM | 1.40-1.60 | 0.10-0.60 | 0.20-0.60 | 11.0-13.0 | 0.50-1.10 | 0.70-1.20 | 0.03max | 0.03max |
| 1.2379 | DIN | 1.45-1.60 | 0.10-0.60 | 0.20-0.60 | 11.0-13.0 | 0.70-1.10 | 0.70-1.00 | 0.03max | 0.03max |
| Cr12mov | GB | 1.45-1.70 | 0.40max | 0.60max | 11.0-12.5 | 0.15-0.30 | 0.40-0.60 | 0.03max | 0.03max |
| SKD11 | JIS | 1.40-1.60 | 0.40max | 0.60max | 11.0-13.0 | 0.20-0.50 | 0.80-1.20 | 0.03max | 0.03max |
2.D2 Tool Steel Bar Size specification:
| Thickness range(mm) | Width range(mm) | Length range(mm) | |
| Rolled Flat bar | 10-60 | 310-910 | 3000-5800 |
| Forged Flat bar | 65-500 | 310-910 | 3000-5800 |
Original Mill origin:Dongbei special(东北特钢),Tiangong(天工),changcheng special(长钢),Huangshi(黄石),JYCRS(华润)
3.D2 Tool Steel Bar Delivery Condition:
Hot rolled or Hot Forged,EAF or ESR
Black surface & Milled surface
Annealled hardness 230HB max
4.D2 Tool Steel Bar Application:
D2 Tool Steel Suitable for impact and extrusion molds of high output, thread twisting molds, molds for ceramics, molds for electric circuit plates and plastic molds of high output.
5.D2 Tool Steel Bar Characteristic:
(1).High hardenability, high wear resistance
(2).High temperature oxidation resistance, heat deformation small
(3).Anti-rust after quenched and polished
6.D2 Tool Steel Typical Applications
Stamping & Blanking Dies: Ideal for long-run production of automotive and electronic parts.
Shear Blades: Heavy-duty knives for slitting and cutting steel strips.
Thread Rolling Dies: High-durability tooling for screw and fastener manufacturing.
Forming Rolls: Precision rollers for tube and pipe production.
Crushers & Shredders: Wear-resistant components for recycling and material processing.
The main products in our company:
Plastic Mould steel: P20/1.2311, 1.2312, 1.2738/718H/P20+NI, NAK80, P40
Hot work tool steel: 1.2344, SKD61, H13, H11, FDAC, 8407
Cold work tool steel: SKD11, D3, 1.2080, 1.2379, CR12MOV, O1, D2
Stainless Stee:1.2083/4CR13/SUS420,1.2085,1.2316,440C
Alloy steel : 4140/42COMO/SCM440/1.7225, 20CR, 40Cr, 35CrMo,SCM420
Carbon steel : S45C/SAE1045/C45, S50C/SAE1045/C50, S55C+CR
Our D2 Tool Steel bar Regular stock:
