D3 Tool & die steel

Model NO.: TOOL & DIE STEEL GRADE
Delivery: FOB,CIF.CFR.EXW
Minimum order quantity: 20 tons
Supply Ability: 1000 tons / Month
Country of Origin: Shenzhen China
Stock Time: 20 Days

AISI D3 (1.2080) is a high-carbon, high-chromium tool steel featuring exceptional abrasive wear resistance and high compressive strength for long-run cold work applications.

It provides superior dimensional stability after heat treatment and is the premier choice for heavy-duty blanking dies, shear blades, and thread rolling tools.

Quantity:

Product Description
Basic Information

D3 TOOL & DIE STEEL

Product Overview

D3 TOOL & DIE STEEL is a premium high-carbon, high-chromium air-hardening tool steel, renowned for its exceptional abrasive wear resistance and high compressive strength. Containing 12% chromium, it forms an extremely high volume of hard carbides, making it the premier choice for long-run tooling applications where maintaining a sharp cutting edge is critical. D3 offers superior dimensional stability after heat treatment, ensuring high precision for complex die designs operating under extreme mechanical stress.

1. D3 TOOL & DIE STEEL Typical Chemical composition:

C	Si	Mn	Cr	S.P
2.00~2.30	<=0.40	<=0.40	11.50~13.00	<=0.030

2. D3 TOOL & DIE STEEL Delivery condition:
  Hot rolled or Hot forged
  Black Surface or Milled Surface
  annealing(hardness max230HB)
EAF or ESR material

3. Size specification

	Thickness range(mm)	Width range(mm)	Length range(mm)
Rolled Flat bar	10-70	310-910	3000-5800
Forged Flat bar	75-500	310-910	3000-5800

We also can produce based on your special request.

4.D3 TOOL & DIE STEEL Process: EF + LF + VD

5. D3 Tool & Die Steel Key Features

Extreme Wear Resistance: Superior carbon content provides unmatched longevity in high-abrasion environments.
High Compressive Strength: Maintains structural integrity under heavy impact and high-pressure loads.
Excellent Dimensional Stability: Exhibits minimal distortion during hardening and tempering processes.
Deep Hardenability: Offers uniform hardening even in thick sections, ensuring consistent performance.
High-Gloss Potential: Capable of achieving an excellent polished finish, suitable for precision molding.

6. Inspection: Ultrasonic test according to SEP 1921-84 Gr3, Class D/d

7. Delivery time:
10-15 days for ready stock
30-60 days for new production products

8. D3 TOOL & DIE STEEL Typical Applications

Punching & Blanking Dies: Ideal for thin or abrasive materials (e.g., silicon steel, stainless steel).
Shearing Blades: High-performance knives for heavy-duty metal cutting.
Drawing & Forming Dies: Used for complex parts requiring high surface finish and low wear.
Thread Rolling Dies: High-durability tooling for screw and bolt production.
Precision Gauges: Used in measuring tools where high stability and wear resistance are critical.
