1.2510/O1 Tool Steel
Product Overview
1.2510 (O1) Tool Steel is a manganese-chromium-tungsten alloyed oil-hardening tool steel. It is widely recognized for its versatility, offering a perfect balance of high surface hardness, excellent machinability, and superior dimensional stability during heat treatment.
Often referred to as the"all-purpose"cold work steel, 1.2510 is the preferred choice for tools where precision and ease of fabrication are paramount.
1)1.2510/O1 Tool Steel Typical Chemical composition:
C=0.85~0.95,Si=0.20~0.40,Mn=1.00~1.30,Cr=0.40~0.60,W=0.40~0.60,V=0.20
2)1.2510/O1 Tool Steel Comparable steel grade:
1.2510 Tool Steel(Germany,DIN)
O1 Tool Steel(USA AISIS)
9CrWMn Tool Steel(China)
SKS3 Tool Steel(Japan JIS)
3)1.2510/O1 Tool Steel Delivery condition:
Hot rolled or forged ,EAF or ESR material,black or machined surface;
Annealing≤229HB
4)1.2510/O1 Tool Steel Dimensions
Flat bar & Block: 6-400 x 205-910X2500-5800mm
Round bar: diameter: 10-500X3000-5800mm
5)1.2510/O1 Tool Steel Material character:
1.2510/O1 Tool steel is an kind of low-alloy cold work tool steel.With certain hardenability and wear resistance, homogenous and small particle carbides.
6)1.2510/O1 Tool Steel Typical Application:
1.2510 is ideal for a vast range of precision tools and components:
Precision Gauges & Measuring Tools: Where dimensional stability is critical.
Cutting Tools: Broaches, taps, reamers, and milling cutters.
Blanking & Piercing Dies: For intricate shapes and medium production volumes.
Guide Rails & Wear Plates: Ensuring smooth motion and long-term durability.
Master Taps & Forming Tools: Used in high-precision engineering.
-------------------------------------------------------------------------------------------------------------------------------------
YUFANG MAIN STEEL LIST:
(1)Plastic Mould steel: P20/1.2311, 1.2312, 1.2738/718H/P20+NI, 1.2083/4CR13/SUS420, NAK80, P40,XPM,1.2085,1.2316
(2)Hot work tool steel: 1.2344, SKD61, H13,1.2343, H11, FDAC, 8407
(3)Cold work tool steel: D2,1.2379,SKD11,Cr12mov, D3, 1.2080, O1
(4)Alloy steel: 4140/42CrMO/SCM440/1.7225, 20CR, 40Cr, 35CrMo,SCM420
(5)Carbon steel: S45C/SAE1045/C45, S50C/SAE1045/C50, S55C+Cr
